CHARGING buzzROD​

​

1. Connect the device to a USB charger or a computer.

2. The red indication will light up.

3. Charge for at least 4hr or until the indication

     light is off.

ADJUSTMENTS​

​

1. Disconnect the USB cable from the charging port.

2. Press and hold the on/off button.

3. Turn the speed adjustment knob clockwise until it clicks.

4. Continue turning until desired vibration power is achieved and release the button.

INSTALLATION

​

1. Attach the rubber stickers between the mounting holes in the designated areas.

2. Align the module to the base of the fishing rod with the control side facing the rod's handle.

3. Starting from the back side of the module, insert the zip tie into the lower mounting hole and back through the upper hole.

4. Repeat on the second pair of holes.

5. Tighten the zip ties firmly. The area between the zip ties must not touch the rod.

6. Trim the tails of the zip ties.

RECOMMENDATIONS

​

The purpose of this device is to produce high frequency vibrations ("buzz") of the rod which the fish can sense. The vibration is a mechanical wave which travels along the line from the module to the lure. To maximize the vibration efficiency follow these recommendations:

        - Use braided fishing line, which does not stretch

        - Keep the line tight while applying the vibration

        - Use with light action rods

        - Use at depths not exceeding 20 feet​

For optimal battery life:

        - Charge before every use

        - Apply the vibration sporadically

        - Avoid using maximum power

SPECIFICATION

​

Battery                                3.7V, 2AHr Li Ion

Charging                                          DC 5V, 1A
IP Rating                                                     IP56
Vibration speed              up to 18,000 RPM
Size                      5.26"L x 2.3.2"W x 0.96"H
Weight                                                           5oz
